SMX-4

SMX-Series professional analog mixer 6 Channels.
2 mono 1 stereo and 2 USB input channels.
48V phantom power supply in each channel.
6 special effects of the sound card.
24-bit DSP digital effect stereo processor each effect can be adjustable separately.
2-In/2-Out, Built-in USB Audio Interface (Audio Player and Recorder)
Built-in Bluetooth 5.2 player.
Built-in digital feedback suppressor.
Power supply for AC 110-240 Voltage.

Verification of compliance :CE | RoHS

SMX-4
Input channels	6
Mono (Mic/Line)	2 (Combo XLR)
Stereo (Line)	1 (TS) (3/4)
Stereo (Line)	1 Phone (TRS)
USB	2
Output channels
Master out	2 (TS)
Phones out	1 (TRS)
Digital I/O	2-in/2-out, USB audio interface (Audio player and recording)
Gain	-10 dB/+60 dB
Input channel EQ
Mono	High: Gain+15dB/-15dB Frequency response: 12kHz(shelving)
	Mid: Gain+15dB/-15dB Frequency response: 2.5kHz(peaking)
	Low: Gain+15dB/-15dB Frequency response: 80Hz(shelving)
Stereo	High: Gain+15dB/-15dB Frequency response: 12kHz(shelving)
Stereo	Low: Gain+15dB/-15dB Frequency response: 80Hz(shelving)
LED level meter	2 x 6 points LED meter (Clip, 8, 6, 0, 6, 24)
Digital effects	24 programs, Control Knob.
Special effects	6 SFX
GENERAL
Frequency response	20Hz-20KHz@+ -0.5dB
Total harmonic distortion	<0.03@1khz
Operating temperature	0°C to 40°C
Phantom power	+48V per channel
Power consumption	15W
Power requirements	110V-240V/50-60Hz
Net weight	1.8Kgs.
Dimensions (W x D x H)	25.521.59.2 CM
