DMC-8800ND
DIGITAL MATRIX AUDIO PROCESSOR WITH DANTE
FEATURES
- ADI SHARC 21489 processor
- Analog input channels : 8 | Analog output channels : 8
- Supports Dante audio network with RJ-45 by primary and secondary.
- 8 balanced microphone or line level inputs on terminal block connectors.
- 8 balanced line level outputs on terminal block connectors.
- Audio interfaces on RJ-45 connectors.
- Built-in 2-in 2-out USB soundcard support web video conference for recording and music playback.
- Supports Apple iOS and MS Windows operating systems.
- Supports adaptive echo cancellation (AEC), adaptive feedback control (AFC), automatic gain control (AGC), automatic mixer control (AMC), automatic noise suppression (ANS).
- Up to 16 settings can be preset providing 5 options parametric, Low-shelf, High-shelf, Low-pass, High-pass.
- Definable GUI (Graphical User Interface) for managing and configuring multiple units.
- Each input supports 8 band parametric equalizer (PEQ), signal generator, compressor, expander, ducker, and 48V phantom power.
- Each output supports 12 band graphic equalizer (GEQ), audio crossover, delayer, limiter.
Specs
| AUDIO | |
| ADSP | ADI SHARC 21489 |
| Audio Format | 24 bits, 48 kHz sampling rates |
| System Latency | < 3 ms |
| Analog I/O Channels | 8×8 |
| Analog Input Gain | 0, 3, 6, 9, 12, 15, 18, 21, 24, 27, 30, 33, 36, 39, 42, 45, 48 dB |
| Analog Input Level | +24 dBu |
| Analog Output Level | +24 dBu |
| Frequency Response | ±0.2 dB (20 Hz to 20 kHz) |
| THD+N | < 0.003% (1 kHz, +4 dBu) |
| Common Mode Rejection Ration | 80 dB (60 Hz) |
| SNR | 110 dB |
| Analog Dynamic Range | 113dB |
| Input Dynamic Range | 110 dB |
| Output Dynamic Range | 120 dB |
| Analog Background Noise | -89 dBu (A-weighted) |
| Channel Isolation | 108 dB (@1 kHz) |
| Input Impedance | 94k Ω (Balanced) |
| Output Impedance | 102 Ω (Balanced) |
| Phantom Power | 48V/10mA max |
| INTERFACE | |
| Input Port | 8 Analog Audio (Terminal Block) |
| Output Port | 8 Analog Audio (Terminal Block) |
| Ethernet Port | 1 Network (RJ-45) |
| Dante Port | 1 Primary (RJ-45) |
| 1 Secondary (RJ-45) | |
| Serial Port | 1 RS-232 (Terminal Block) |
| 1 RS-485 (Terminal Block) | |
| GP I/O Port | 8 GPI/O (Terminal Block) |
| USB Port | 1 USB Audio (Type-A) |
| GENERAL | |
| Power voltage | AC 110V ～ 240V : 50Hz/60Hz |
| Power consumption (IEC) | 25 W |
| Operating Temperature | 0 to +40 °C |
| Humidity | 10% to 90% RH (non-condensing) |
| Dimensions (W x D x H) | 445 × 241 × 30 mm |
| Weight | 3 kgs. |
