CSI-06

6-Inch Ceiling Speaker 100V 6W

CSI-06 6-inch ceiling speaker 6Watts is ideal for indoor applications requiring high-quality sound, designed for a wide range of commercial line transformers with multiple for use in 100V Taps at 100V: 6W/3W, 6W@8Ω

CSI-06 Applications designed suitable, such as hotels, restaurants, bars, lounges, training and conference rooms, or shopping centers.

FEATURE

  • 6-inch ceiling loudspeaker for installation
  • Elegant design.
  • Easy to installation
  • High-quality sound.
  • Frequency response 110Hz~15KHz
  • Transformer taps 100V: 6W/3W, 6W@8Ω

SPECIFICATIONS

Speaker type Ceiling loudspeaker
Rated power 3W 6W
Line voltage 100V
Transformer taps 100V : 6W/3W, 6W@8Ω
Frequency response 110Hz~15KHz (-3dB)
Sensitivity 1W/1m 90 ±3dB
Maximum SPL/1m (calc) 97dB
Coverage Angle Conical 160°
Speaker driver 6-inch
Nominal impedance (Passive)
Operating temperature -20°C to +55°C
Connections A length of connecting cable
Indoor applications Yes
Color White
Cabinet material ABS enclosure
Front grille Metal grille
Dimentions hole for mounting Ø165 mm.
Dimentions  Ø190 x H 105 mm. (without bracket)
Weight 1.47 Kg





DOWNLOAD
